Accessories

EXAIR offers a complete line of accessories.

Valves

Model	Description
9012	Manual Valve, 1/4 NPT
900340	Manual Valve, 3/8 NPT
900343	Manual Valve, 1/2 NPT
900743	Manual Valve, 3/4 NPT
900346	Manual Valve, 1 NPT
900744	Manual Valve, 1 - 1/4 NPT
9040	Foot Pedal Valve, 1/4 NPT

Solenoid Valves

solenoid valves

RoHS compliant

Solenoid Valves are available in a variety of flow rates and voltages. All models are UL Listed and are CE and RoHS compliant.

Model #	Description
9018	NEMA 4-4X Solenoid Valve, 110V-120V, 50/60Hz, 1/4 NPT, 40 SCFM (1133 SLPM)
9020	Solenoid Valve, 120V, 50/60Hz, 1/4 NPT, 40 SCFM (1133 SLPM)
9021	Solenoid Valve, 200-240V, 50/60Hz, 1/4 NPT, 40 SCFM (1133 SLPM)
9024	NEMA 4-4X Solenoid Valve, 240V, 50/60Hz, 1/4 NPT, 40 SCFM (1133 SLPM)
9059	NEMA 4-4X Solenoid Valve, 24VDC, 1/4 NPT, 200 SCFM (5664 SLPM)
9031	Solenoid Valve, 24VDC, 1/4 NPT, 40 SCFM (1133 SLPM)
9034	Solenoid Valve, 120V, 50/60Hz, 1/2 NPT, 100 SCFM (2832 SLPM)
9035	Solenoid Valve, 240V, 50/60Hz, 1/2 NPT, 100 SCFM (2832 SLPM)
9058	NEMA 4-4X Solenoid Valve, 24VDC, 1/2 NPT, 100 SCFM (2832 SLPM)
9036	Solenoid Valve, 120V, 50/60Hz, 3/4 NPT, 200 SCFM (5664 SLPM)
9037	Solenoid Valve, 240V, 50/60Hz, 3/4 NPT, 200 SCFM (5664 SLPM)
9065	Solenoid Valve, 24VDC, 1 NPT, 350 SCFM (9911 SLPM)

Thermostat

The adjustable thermostat is factory set at 95°F (35°C). It will normally hold ±2°F (1°C) of the desired temperature setting. It is rated 24V-240V AC or DC, 50/60 Hz and is UL Recognised, CSA Certified.

Model	Description
9017	Thermostat

Compliant

Magnetic Base

Model 9029

Model 9042

Model 9043

Magnetic bases are suited to applications where frequent movement of the air product is required. The powerful magnet permits horizontal or vertical mounting. A shutoff valve is provided that can be used to infinitely vary the force and flow.

Model	Description
9029	One Outlet Swivel Magnetic Base with Shutoff Valve
9042	One Outlet Magnetic Base with Shutoff Valve
9043	Two Outlet Magnetic Base with Shutoff Valve

Swivel Fittings

EXAIR's Swivel Fittings make it easy to adjust the position of the Air Nozzles, Air Jets and Air Amplifiers. Swivel Fittings permit a movement of 25 degrees from the centre axis for a total movement of 50 degrees. Type 303 Stainless Steel.

Model	Description
9052	1/8 NPT Swivel Fitting
9053	1/4 NPT Swivel Fitting
9068	3/8 NPT Swivel Fitting
9069	1/2 NPT Swivel Fitting
9023	3/4 NPT Swivel Fitting

Swivel Fittings can be used with Air Nozzles and many other EXAIR products. They are available in 1/8,1/4, 3/8,1/2 and ¾ NPT sizes.

Drum Dolly

The Model 9041 55 Gallon Drum Dolly has a 900 lb capacity and works with our Chip Vac and Reversible Drum Vac.Easy to roll, heavy-duty dolly makes it easy to transport 55 gallon drums 3" diameter ball bearing swivel casters that resist oil, water and impact. All welded steel construction, zinc plated nuts and bolts

Model	Capacity (lbs)	Drum Size (gal.)	Inside Diameter (in.)	Ship Weight (lbs.)
9041	900	55	23-3/4	28

The Model 9041 Drum Dolly makes it easy to move the Chip Vac or Drum Vac from one work area to another.

Air Hose

Model	Description
Compressed air hose (3/8" ID) is constructed of reinforced synthetic rubber to assure long life and protection against ozone, weathering, and temperatures up to 158°F (70°C). Includes a 1/4 NPT male brass fitting on each end. Hose lengths are 10', 20', 30', 40' and 50'. Indicate the length with a dash. Example: A Model 900061-30 is a 30' long compressed air hose.
900061-	Compressed Air Hose, 1/4 NPTM x 1/4 NPM

Conveying Hose
Hose lengths are 10', 20', 30', 40' and 50' (3.05m, 6.10m, 9.14m, 12.19m and 15.24m). Select the hose model number (diameter) and indicate the length with a dash. Example: A Model 6931-20 is 1" ID Hose x 20' long.
Model #	Description	Model #	Description	Model #	Description
6928-	Hose 3/8" ID	6931-	Hose 1" ID	6934-	Hose 2" ID
6929-	Hose 1/2" ID	6932-	Hose 1-1/4" ID	6935-	Hose 2-1/2" ID
6930-	Hose 3/4" ID	6933-	Hose 1-1/2" ID	6936-	Hose 3" ID

12 Foot (3.05m) Coiled Hoses
Model #	Description		Model #	Description		Model #	Description
900106	1/8 NPT Coiled Hose With Swivel		900750	1/4 NPT Coiled Hose With Swivel		900751	3/8 NPT Coiled Hose With Swivel

Compressed Air Fittings

Hex Nipple
Model #	Material	Thread Size
9890	Brass	1/8 NPTM x 1/8 NPTM
9944	Brass	1/4 NPTM x 1/4 NPTM
9759	Brass	3/8 NPTM x 3/8 NPTM
9760	Brass	1/2 NPTM x 1/2 NPTM
9761	Brass	3/4 NPTM x 3/4 NPTM
9958	304SS	1/8 NPTM x 1/8 NPTM
9959	304SS	1/4 NPTM x 1/4 NPTM
9960	304SS	3/8 NPTM x 3/8 NPTM
9961	304SS	1/2 NPTM x 1/2 NPTM

Close Nipple
Model #	Material	Thread Size
9551	Brass	1/4 NPTM x 1/4 NPTM
9752	Brass	3/8 NPTM x 3/8 NPTM
900745	Brass	1/2 NPTM x 1/2 NPTM
900559	Brass	3/4 NPTM x 3/4 NPTM
900309	NP Brass	1/8 NPTM x 1/8 NPTM
900084	NP Brass	1/4 NPTM x 1/4 NPTM
900435	NP Brass	3/8 NPTM x 3/8 NPTM
900436	NP Brass	1/2 NPTM x 1/2 NPTM
900409	316SS	1/8 NPTM x 1/8 NPTM
900160	316SS	1/4 NPTM x 1/4 NPTM
900505	316SS	3/8 NPTM x 3/8 NPTM
900506	316SS	1/2 NPTM x 1/2 NPTM

Coupler
Model #	Material	Thread Size
900453	NP Brass	1/8 NPTF x 1/8 NPTF
9871	Brass	1/4 NPTF x 1/4 NPTF

* NPTM = NPT Male, NPTF = NPT Female, NP = Nickel Plated

Reducer
Model #	Material	Thread Size
900405	Brass	1/4 NPTM x 1/8 NPTF
900105	Brass	1/4 NPTF x 1/8 NPTM
9946	Brass	1/4 NPTM x 1/8 NPTF
9553	Brass	3/8 NPTM x 1/4 NPTM
9897	Brass	1/2 NPTM x 3/8 NPTM
900736	Brass	1/2 NPTM X 1/4 NPTM
900967	Brass	1/2 NPTF X 1/4 NPTF
900985	Brass	1/2 NPTF X 3/8 NPTM
900622	Brass	1/2 NPTM x 1/4 NPTF

Tee
Model #	Material	Thread Size
900005	Brass	1/4 NPTF x 1/4 NPTF x 1/4 NPTM
9851	Brass	1/4 NPTM x 1/4 NPTM x 1/4 NPTM
9971	Brass	3/8 NPTF x 1/4 NPTF x 3/8 NPTM
9896	Brass	3/8 NPTF x 3/8 NPTF x 3/8 NPTF
900621	Brass	1/2 NPTF x 1/2 NPTF x 1/2 NPTF
900734	Brass	1/2 NPTF x 1/4 NPTF x 1/2 NPTF

Elbow
Model #	Material	Thread Size
7674	Brass	1/8 NPTM x 1/8 NPTF 45°
9555	Brass	1/4 NPTM x 1/4 NPTF 90°
9895	Brass	3/8 NPTM x 3/8 NPTF 90°
900073	Brass	1/4 NPTM x 3/8 Tube 90°

Cross
Model #	Material	Thread Size
900735	Brass	1/2 NPTF x 1/2 NPTF

Bulkhead Fitting
Model #	Material	Thread Size
900069	Brass	3/4 NPTM x 1/4 NPTF

*NPTM = NPT Male, NPTF = NPT Female, NP = Nickel Plated

Mufflers and Filters
EXAIR Silencing Mufflers help to reduce work area noise produced by air exhausting from cylinders, valves and other air powered equipment. Per OSHA standard 1910.95, a worker must not be exposed to sound levels above 90 dBA for any eight hour shift of a 40 hour work week. Silencing Mufflers help plants meet this OSHA requirement by reducing the sound to safe levels below 90 dBA. They also eliminate harmful dead ended pressures. Each style of Silencing Muffler shown has a high airflow capacity, with low back pressure. Popular NPT sizes are ideal for new and existing installations. EXAIR's Filter Separators remove water, dirt and rust from your compressed air system. They prevent these contaminants from plugging or damaging the compressed air products.

Stay Set Hoses
For applications where frequent repositioning of the Air Nozzle or Jet is required, the Flexible Stay Set Hoses are ideal. Simply mount the hose in close proximity to the application and bend it to aim the airstream at the target. Since the hose has "memory", it will not creep or bend. It always keeps the aim until physically moved to the next position.
